Air CoolingUnity HV2
72-253kWh
Stacked C&I Battery
| Model | Ebox 16 Pro |
| Nominal Voltage (VDC) | 51.2 |
| Capacity (Ah) | 314 |
| Nominal Capacity (kWh) | 16.076 |
| Built-In Circuit Breaker | 125A,2P |
| Nominal Charge/Discharge Current (A) | 200/200 |
| Max Charge/Discharge Current (A) | 200/200 |
| Cycle Life | 8000 @90%DOD,25 ℃ ,0,5C |
| Display | LCD indicator |
| Structure | |
| Dimensions (W*D*H)(mm) | 465*240*960 |
| Weight (kg) | 120 |
| IP Rating | IP65 |
| Installation | Stacked, Wall-Mounted, Floor-Standing |
| Working Environment | |
| Charge Working Temperature ( ℃ ) | 0~55 (-20~55 with heating function) |
| Discharge Working Temperature ( ℃ ) | -20~55 |
| Altitude (m) | <2500 |
| Humidity (RH) | 5-95% |
| Communication/Warranty | |
| Communication Port | RS485,CAN |
| Warranty Period | 10 years |
| Certificates | CB, IEC62619,CE-EMC, EN61000, UL9540A, UN38.3, MSDS |
| Compatible Inverter List | SOLIS, DEYE, GROWATT, VICTRON, AFORE, GOODWE, Voltronic, Gospower, SRNE, FELICITY... |
