| Model | Rove 3.6kW | Rove 6.0kW | Rove 12.0kW | |
| AC Input | ||||
| Rated Input Voltage (VAC) | 208/220/230/240；L+N+PE | 220/230/240；L+N+PE | ||
| Voltage Range (VAC) | 90~280±3 (APP/GEN mode); 170~264±3 (UPS mode) | |||
| Frequency (Hz) | 50/60 (Auto adaptive) | |||
| AC Output | ||||
| PV Inverter Rated Power Output (kW) | PV Inverter Output | 3.6 | 6.0 | 12 |
| Battery Inverter Output | 3.6 | 6.0 | 10 | |
| Battery Inverter Rated Power Output (kW) | 3.6 | 6.0 | 10 | |
| Peak Power (kVA) | 7.2 | 12 | 24 | |
| Voltage (VAC) | 208/220/230/240±5% | 220/230/240±5% | ||
| Power Factor (PF) | 1 | |||
| Frequency (Hz) | 50/60±0.1% | |||
| Switch Time (ms) | 10 (APP/UPS mode); 20 (GEN mode) | |||
| Wave Form | Pure sine wave | |||
| Overload Capacity (Battery Mode) | 1min@102%-110% load; 10s@110%-200% load | 1min@102%~120% load; 10s@120%~200% load | 1min@102%~125% load; 10s@125%~200% load | |
| Max. Efficiency (Battery Mode) | 92.7%@24VDC | 94%@48VDC | 94%@48VDC | |
| Charger (PV/AC) | ||||
| Solar Charger Type | MPPT | |||
| Max PV Input Current/Input Power | 18A/5000W | 27A/9000W | Using One MPPT: 27A/9KW Using Two MPPTs: 22.5A/Per MPPT, 15KW/Total | |
| MPPT Range@Operating Voltage (VDC) | 40-450 | 60-450 | 60-450 | |
| Max PV Open Circuit Voltage (VDC) | 500 | |||
| Max. Charge Current (PV/AC)(A) | 100 | 120 | 160 | |
| Battery | ||||
| Rated Voltage (VDC) | 24 | 48 | 48 | |
| Floating Charge Voltage (VDC) | 27 | 54 | 54 | |
| Overcharge Protection (VDC) | 30.5 | 61 | 61 | |
| Battery Type | Lithium or Lead-acid | |||
| Interface | ||||
| HMI | LCD | |||
| Interface Module | RS485/RS232/CAN | |||
| Monitoring | WiFi (Optional) | |||
| General Data | ||||
| Ingress Protection | IP21 | |||
| Operating Temperature (℃) | -10~60 | |||
| Relative Humidity | 20%~95%(Non-condensing) | |||
| Storage Temperature (℃) | -15~60 | |||
| Net Weight (kg) | 5.8 | 7.6 | 15 | |
| Dimensions (W*D*H)(mm) | 284*95*432.5 | 330*110*402.5 | 420*120*503.6 | |
| Max Operating Altitude (m) | 4000 (Derating above 1000) | |||
| Model | Rove 6.0kW | Rove 12kW | |
| AC Input | |||
| Rated Input Voltage (VAC) | 208/220/230/240, L+N+PE | 220/230/240, L+N+PE | |
| Voltage Range (VAC) | 90-280±3(APP/GEN mode), 170-264±3(UPS mode) | ||
| Frequency (Hz) | 50/60(Auto adaptive) | ||
| AC Output | |||
| Rated Power (kW) | PV Inverter Output | 6.4 | 12 |
| Battery Inverter Output | 6 | 10 | |
| Peak Power (kVA) | 12 | 24 | |
| Voltage (VAC) | 208/220/230/240 ±5% | 220/230/240 ±5% | |
| Power Factor (PF) | 1 | ||
| Frequency (Hz) | 50/60±0.1% | ||
| Switch Time (ms) | 10 (APP/UPS mode); 20 (GEN mode) | ||
| Wave Form | Pure sine wave | ||
| Overload Capacity (Battery Mode) | 1min@102%~120% load; 10s@120%~200% load | 1min@102%~125% load; 10s@125%~200% load | |
| Max. Efficiency (Battery Mode) | 94%@48VDC | ||
| Parallel Quantity | 9 | 6 | |
| Charger (PV/AC) | |||
| Solar Charger Type | MPPT | ||
| Max PV Input Current/Input Power | 27A/9000W | Using One MPPT: 27A/9KW Using Two MPPTs: 22.5A/Per MPPT, 15KW/Total | |
| MPPT Range@Operating Voltage (VDC) | 60-450 | 60-450 | |
| Max PV Open Circuit Voltage (VDC) | 500 | ||
| Max. Charge Current (PV/AC)(A) | 120 | 160 | |
| Battery | |||
| Rated Voltage (VDC) | 48 | ||
| Floating Charge Voltage (VDC) | 54 | ||
| Overcharge Protection (VDC) | 61 | ||
| Battery Type | Lithium or Lead-acid | ||
| Interface | |||
| HMI | LCD | ||
| Interface Module | RS485 / RS232/ CAN | ||
| Monitoring | WiFi (Optional) | ||
| General Data | |||
| Ingress Protection | IP21 | ||
| Operating Temperature (℃) | -10~60 | ||
| Relative Humidity | 20%~95%(Non-condensing) | ||
| Storage Temperature (℃) | -15~60 | ||
| Net Weight (kg) | 8.2 | 15 | |
| Dimensions (W*D*H)(mm) | 330*110*402.5 | 431.7*121.5*503.6 | |
| Max Operating Altitude (m) | 4000 (Derating above 1000) | ||
