Air CoolingUnity HV2
72-252kWh
Stacked C&I Battery
| Model | UX-15.3-HPB | UX-20.4-HPB | UX-25.6-HPB | UX-30.7-HPB | UX-35.8-HPB | UX-40.9-HPB | UX-46-HPB | UX-51.2-HPB | UX-56.3-HPB | UX-61.4-HPB |
| Battery Type | LFP | |||||||||
| Battery Pack Number | 3 | 4 | 5 | 6 | 7 | 8 | 9 | 10 | 11 | 12 |
| Nominal Energy (kWh) | 15.36 | 20.48 | 25.6 | 30.72 | 35.84 | 40.96 | 46.08 | 51.2 | 56.32 | 61.44 |
| Discharge Voltage (V) | 129.6 ~172.8 | 172.8 ~230.4 | 216 ~288 | 259.2 ~345.6 | 302.4 ~403.2 | 345.6 ~460.8 | 388.8 ~518.4 | 432 ~576 | 475.2 ~633.6 | 475.2 ~633.6 |
| Rated Voltage (V) | 153.6 | 204.8 | 256 | 307.2 | 358.4 | 409.6 | 460.8 | 512 | 563.2 | 614.4 |
| Rated Working Current (A) | 50 | |||||||||
| Max Charging Current (A) | 70 | |||||||||
| Max Discharging Current (A) | 100 | |||||||||
| Certificates | IEC62619, EN61000-6-1/3, UN38.3 | |||||||||
| General Data | ||||||||||
| Display | LED | |||||||||
| Communciation Interface | RS485/CAN | |||||||||
| Dismensions Interface (W*D*H)(mm) | 550*600*1050 | 550*60*1450 | 550*600*2050 | |||||||
| Weight (Kg) | 165 | 165 | 253 | 297 | 350 | 394 | 438 | 485 | 529 | 573 |
| Working Temperature Range (℃) | Charging：5～50；Discharging：-20～55；Storage：-20～50 | |||||||||
| Operating Humidity Range | 5%RH～95%RH,No condensation | |||||||||
| Altitude (m) | 3000 | |||||||||
| Cooling Method | Natural Cooling | |||||||||
| IP Rating | IP20 | |||||||||
| Installation Method | Rack mounted (optional installation rack) | |||||||||
| Scalability | 3~12 | |||||||||
| Battery Pack | ||||||||||
| Model | UX-5.1-HPB | |||||||||
| Battery Pack Specifications | 51.2V/5.12kWh/100Ah | |||||||||
| Life Cycles | 6000@90%DOD，25℃/0.5C | |||||||||
| Dimensions (W*D*H)(mm) | 483*550*130 | |||||||||
| Weight (Kg) | 44 | |||||||||
