Cube125/161/192
户外分布式储能（风冷）
| Model | RX-6.0-HM3 |
Output rating | 6kVA |
| Max capacity | 9kW |
| MPPT voltage range | 180-850V |
Max DC voltage | 1000V |
| Max output current | 8.7A |
Dimension(W*D*H, mm) | 530*200*600 |
| Weight | 29kg |
| Certifications | IEC/EN62109-1/-2, IEC/EN62477-1, IEC/EN 61000-6-1, IEC/EN 61000-6-3, Europe：EN50549-1, Germany:VDE4105/0124, UK:G99, South Africa:NRS097-2-1:2017 |
| Model | RX-8.0-HM3 |
Output rating | 8kVA |
| Max capacity | 12kW |
| MPPT voltage range | 180-850V |
Max DC voltage | 1000V |
| Max output current | 11.5A |
Dimension(W*D*H, mm) | 530*200*600 |
| Weight | 29kg |
| Certifications | IEC/EN62109-1/-2, IEC/EN62477-1, IEC/EN 61000-6-1, IEC/EN 61000-6-3, Europe：EN50549-1, Germany:VDE4105/0124, UK:G99, South Africa:NRS097-2-1:2017 |
| Model | RX-10.0-HM3 |
Output rating | 10kVA |
| Max capacity | 15kW |
| MPPT voltage range | 180-850V |
Max DC voltage | 1000V |
| Max output current | 14.4A |
Dimension(W*D*H, mm) | 530*200*600 |
| Weight | 29kg |
| Certifications | IEC/EN62109-1/-2, IEC/EN62477-1, IEC/EN 61000-6-1, IEC/EN 61000-6-3, Europe：EN50549-1, Germany:VDE4105/0124, UK:G99, South Africa:NRS097-2-1:2017 |
| Model | RX-12.0-HM3 |
Output rating | 12kVA |
| Max capacity | 18kW |
| MPPT voltage range | 180-850V |
Max DC voltage | 1000V |
| Max output current | 17.3A |
Dimension(W*D*H, mm) | 530*200*600 |
| Weight | 29kg |
| Certifications | IEC/EN62109-1/-2, IEC/EN62477-1, IEC/EN 61000-6-1, IEC/EN 61000-6-3, Europe：EN50549-1, Germany:VDE4105/0124, UK:G99, South Africa:NRS097-2-1:2017 |
| Model | RX-15.0-HM3 |
Output rating | 15kVA |
| Max capacity | 22.5kW |
| MPPT voltage range | 180-850V |
Max DC voltage | 1000V |
| Max output current | 21.7A |
Dimension(W*D*H, mm) | 530*200*600 |
| Weight | 29kg |
| Certifications | IEC/EN62109-1/-2, IEC/EN62477-1, IEC/EN 61000-6-1, IEC/EN 61000-6-3, Europe：EN50549-1, Germany:VDE4105/0124, UK:G99, South Africa:NRS097-2-1:2017 |
